Stoelting Pass Thru S.S. on all wetted surfaces (7)W, R, FR, ABO, DRY, Cooling, RI
Have one to sell?
ConditionUsed
1 available
Just removed from service.
If you need a quality parts washer Stoelting is as good as it gets. Still in business, and are able to support all of their units with drawings, parts, etc.
Unit is set up for Special Cleaning Spec.
Flow is as follows:
2' Conveyor Extension.
9" Load
3'-6" Wash 9" Exit
9" Load Rinse, 3'-6" Rinse 9" Exit
2' Final Rinse Cascade to Rinse
1'-9" Ambient Blow-Off
9" Then Blow-Off of 3'-6", 9" Exit
3' Cooling Section 9" Exit
3'-6" Rust Inhibitor 9" Exit,
2' Conveyor Extension Exit
12" Wide Belt 14" Clearance Width
Part Height 12"
Construction: S.S. (Stainless Steel)
Tanks 14 GA S.S.
Canopies 14 GA S.S.
Blow Construction S.S.
Chip Basket S.S.
Piping S.S.
Spray Tubes S.S.
Pumps S.S.
Conveyor Belting S.S. 12" Wide 1x1 Mesh
1/2 HP Drive Motor
1/4 HP Drive Motor RI Sect
Belt Sprockets S.S.
Canopy Venting W/R
Vent Fan 1/3 HP Aluminum Construction
Rating 321 CFM @ 1.25 S.P.
Discharge 4" Diam. Slip Collar
Damper Controlled
Filtration Option W/R
Model No. 44-12 Filter Housing
Carbon Steel Construction W/ S.S. Piping
Size #4 Bags 100 Micron
Oil Coalscing Option
Hyde Model CF-1/2-A-SS
Cross Flow Seperator
Stainless Steel Tank, CPVC Piping
W/Pneaumatic Pump 1/4" NPT Connection
Utilities:
Incoming Water 40 PSI Max 125 PSI
Note Soft Water Recommended
Elctrical 460 Volt 3 Phase
Oil Coalscer
Chemical Mixer Connection
Vent Fans
80 Gallon Wash Tank 36 GPM, 1-1/2 HP SS Pump, 26 KW Electric Heat 150 Deg. F. , 100 Micron Filter
80 Gallon Rinse Tank 36 GPM, 1-1/2 HP SS Pump, 26 KW Electric Heat 150 Deg. F. , 100 Micron Fiter
Final Rinse 1.6 GPM
Ambient Blow-Off 350 CFM 3HP
Heated Blow-Off 1000 CFM, 5 HP, 250 Deg. F.
RI Section 80 Gallon Tank, 36 GPM, 1-1/2 HP Pump with Viton Seals Compatible iwth Cimguard 20 RI
Access Covers
Sound Enclosures
Clean Out Covers
Chip Trays
