Late Model Stoelting Parts Washer 24" Wide x 12" Part Height (3) Stage WRD
Have one to sell?
ConditionUsed
1 available
Recently Removed from Service – Excellent Condition!
Stoelting is known for manufacturing some of the highest-quality parts washers on the market, sparing no expense in engineering and construction. This particular unit originally sold for over $300,000 and remains in immaculate condition.
If you’re seeing this listing, you have the rare opportunity to own a premium Stoelting parts washer at a substantial discount.
This unit was originally sold with a custom fixture belt. We recommend the new owner retrofit it with a 1x1" mesh belt and upgrade to a 24" wide belt. This is a straightforward process—Stoelting has confirmed they can provide all necessary parts for the modification.
Don’t miss out on this incredible deal!
All wetted surfaces, including pumps and plumbing, are constructed from stainless steel—the most premium and durable option available for a parts washer. This ensures maximum longevity, corrosion resistance, and reliability. No expense was spared in the design and build of this unit
Flow:
3' Load
5' Wash
5' Rinse
5' Dryer
3' Unload
GENERAL CONSTRUCTION:
Tanks 12 Gauge Stainless Steel
Canopies 14 Gauge Stainless Steel
Chip Baskets Stainless Steel
Piping Stainless
Spray Headers Stainless
Heated Blow-Off Construction Stainless Steel
Conductivity Monitors in Wash and Rinse Tanks
Dosatron Chemical Injection (Wash Only)
CONVEYOR CHAIN:
Wash Rinse Dry
(2) Strands of C-2602 Stainless Steel Roller Chain
With K1 Attachments 1-1/2" Pitch Oversized Rollers
With Part Fixtures at 12.00" Centers
Belt Sprockets: Stainless Steel
1 HP Variable Speed AC Drive Motor .5 to 5 FPM
UTILITES:
Incoming water:
Nominal 40 PSI
Maximum 125 PSI
Tank Fill: 3/4" NPT Tank Drains 2" NPT
Electrical: 460 V/60HZ/3PH
CANOPY VENTING:
Mist Collector NUTECH ME1400XC 3 HP 460 V 1400 CFM
PUMPS:
316 Stainless Steel Fitted, Sealless, Painted Exterior
FILTRATION: Rosedale Model NCO-830 Stainless Steel Housing W/100 Micron Bags Wash & Rinse Stages.
OIL REMOVAL:
PRAB Model CF2-2A-SS Cross Flow Separator Stainless Steel Construction
2 GPM Oil Pickup Rating
1 SCFM @ 20 PSI Air Required 1/4" NPT Air Inlet
HEAT SPECS:
42 KW Electric Immersion Heaters
(4) 10.5 KW Heaters In Wash & Rinse Tanks
30 KW Modular Duct Heaters
(5) 6 KW Heaters in Heated BlowOff Tank
150 Gallon Wash Tank 3 HP Gusher Stainless Steel Pump 52 GPM, 140 Deg. F.
150 Gallon Rinse Tank 3 HP Gusher Stainless Steel Pump 36 GPM, 140 Deg. F.
7.5 HP 1000 CFM Blower 250 Deg. F
Canopy Access Doors with Safety Switches
Solution Tank Access Doors
Remote Stat Stop E-Stop at each end.
